DTI-646 Tunnel Drying Oven
Customer directive
Our customer wanted to create an indexing single part flow inert atmosphere production furnace system to match, and seamlessly integrate into, the customer’s entire existing manufacturing process at a production rate of 45 seconds part to part. The customer’s then existing process included inefficient batch furnace staging of parts at this point in the process.
Description
The DTI-646 industrial oven is used to dry a coating applied to strands of polyethylene fibers used in making fishing line. This drying oven processes eight (8) strands of line through the chamber. All equipment used to pull the product through the heated chamber is provided by the customer.
Specifications
| Overall Dimensions | 10′-6″ L x 4′-1″ W x 5′-1″ H (3200mm x 1245mm x 1549mm) |
| Interior Dimensions | 10′-8″ L x 1′-8″ W x 1′-0″ H (3251mm x 508mm x 305mm) |
| Insulation Thickness | 3″ (76mm) |
| Heat Source | Single electric heater controlled by SCR |
| Maximum Operating Temperature | 300°F (149°C) |
| Operating Temperature Range | 180°F – 300°F (82°C – 149°C) |
| Fans | One (1) circulation fan, One (1) exhaust fan |
| Airflow | Vertical down |
| Operating Voltage | 480-volt / 3-phase / 60-hertz |
| Misc | Digital indicating temperature controller |
| Digital indicating over temperature controller |
Alternative capabilities
Davron Technologies, Inc. provides process specific industrial inert atmosphere oven applications, including the following:
- Industries Served: Automotive, Pharmaceutical / Medical, Aerospace, Glass, Composites
- Materials/Parts Processed: Castings, Glass, Plastics, Steel, Engine Components, Cast Steel/Aluminum
- Process Applications: Inert Stress Relieving, Inert Atmosphere Annealing, Inert Atmosphere Batch, Inert Atmosphere Conveyor/Continuous
